HOME KIT SETUP


Camera SETUP

1: SET CAMERA AND MIC ON YOUR DESK, RAISE TRIPOD

Take out the camera kit assembly and the microphone. Place them on your desk.

   • Open case: unlock, open latches




   • Unfold the tripod legs: pull legs apart from the bottom




   • Raise the tripod: pull top of the tripod away from the bottom

   • Place tripod behind computer: adjust camera above computer

   • Tilt tripod head as needed: use screw to tighten/loosen




   • Place microphone in front of your computer


​

​

2: PLUG IN CABLES

Plug in the cables to the USB hub included and plug the hub into your computer
   • There are two hubs provided
           • USB A
           • USB C
   • Lights on the camera and microphone will turn on when connected correctly
   • If needed, power on the camera by pressing the power button

​

3: SELECT CAMERA IN ZOOM SETTINGS: "MEVO"

Open Zoom’s VIDEO SETTINGS tab
   • (Click your profile icon > “Settings” > “Video”)
   • From the CAMERA dropdown, choose “Mevo”

​

4: SELECT MIC IN ZOOM SETTINGS: "SHURE MV7"

In the Zoom settings window, navigate to the AUDIO SETTINGS tab
   • In the SPEAKER dropdown, choose your headphones (or your speakers)
   • From the MICROPHONE dropdown, choose “Shure MV7”


5: ADJUST COMPOSITION AND LIGHTING

Power on the lighting unit by pressing and holding the button on the right side
   • Adjust intensity using the top scroll wheel
   • Adjust color temperature using the middle scroll wheel

​




6: GO ON AIR!

Join the Chief team for technical checks before your event
   • We will be able to answer any questions
   • Have a great show!

​

For more advanced information on audio/video tips & tricks, see our Presenter Resources.

​

EQUIPMENT SPECIFICS

For manufacturer guides for the main elements of the Studio in a Box, click the links below:

​

​

​
